Small sized crimping tool

Weidmuller USA has developed and launched the PZ 2.5 S, a small professional crimping tool for wire end ferrules. In control cabinet construction, cables of the most diverse cross-sections are fitted with wire end ferrules. On average, 90% of these connections are in a cross-section range of AWG 14 (2.5mm2) and smaller. A focus on this cross-section range makes the PZ 2.5 compact and ergonomic. The small handle width and the opening angle, as well as the weight, make the tool easy to use without incurring fatigue in the hand, wrist, or arm. The PZ 2.5 tool features a length of 160mm with a small grip width so it can easily fit in the palm of the hand. Weighing around 10oz, this compact tool is light to carry around for ergonomic advantage. The trapezoidal crimp in the cross-section range of AWG 26 to AWG 14 (0.14-2.5mm2) complies with all current standards. The practical universal die prevents incorrect insertion and ensures error-free work. The focus on small cross-sections also reduces wear, leading to a doubling of the service life of the PZ 2.5.

Weidmüller Group |


Volume: 2024 March/April
