Next-generation multi-circuit meter

Socomec introduces the DIRIS MCM-48, the next-generation multi-circuit meter for retrofit and sub-metering applications. The DIRIS MCM-48 is a revenue-grade networked energy and power sub-meter with 48 individual current sensor inputs, allowing users to monitor up to (16) three-phase circuits or a combination of three-phase, two-phase, and single-phase circuits. It has been designed with mechanical, electrical, and software features that will appeal to those seeking a simplified approach to installation and setup of energy management applications all while providing durability. It supports 333mV and Socomec Rogowski rope-style current sensors, suitable for retrofit applications. When associated with the Socomec RF interfaces, DIRIS MCM-48 power meters from different locations throughout a facility can communicate their measurements wirelessly to a central Hub, which significantly reduces installation and wiring time. Its advantages include increased safety, industrial design, easy installation, smart CT-correct algorithm, and wireless communication. Compliant with UL 61010-1, CSA-C22.2 No 61010-1-12, ANSI C12.1 Class 0.2.

Socomec |

Volume: 2024 March/April
