Highly efficient modular inverter systems

UNIPOWER LLC's family of Bravo inverters provide customers with a highly efficient and modular AC or DC power solution. The Bravo inverters offer a modular and fully scalable solution using hot-swap inverter modules at 2.5kVA 120VAC or 3kVA 230VAC. The Bravo ECI and TSI models are compact 2U (3.5") rackmount inverters that can be configured with up to four 2.5kVA modules totaling 10kVA in a single 2U shelf. Units can be connected in parallel to increase the overall output of the inverter system and the hot-swappable modules can also be configured with N+1 redundancy. The Bravo models provide extra AC input to ensure a high overall efficiency that results in a reduction of energy loss and heat dissipation. Both Bravo inverter models convert 48VDC into a pure sine wave with an output of 120VAC or 230VAC. Outputs can be configured to deliver single-, dual-, or three-phase AC power. For enhanced system communications, UNIPOWER offers a translator interface PCB that allows the inverters to seamlessly communicate with the existing UNIPOWER ACX controller through the PowCom network software. PowCom allows system communication through a local or remote PC and will automatically adjust its interface to the capabilities of the connected system, eliminating the need for two separate protocols.

UNIPOWER | www.unipowerco.com
