25A rapid shutdown products New!

14 Sep 2022

The new 25-Amp Tigo TS4 devices offer plug-and-play support for all solar modules up to 700W (one module for TS4-A-F 25A and two 700W modules for TS4-A-2F 25A) and rated for a maximum short current of 25A and a maximum input voltage of 80V per module; compliance with NEC 2017 and 2020 690.12 Rapid Shutdown specifications when installed with the Tigo RSS Transmitter and UL PVRSS certified inverter or an inverter with a built-in Tigo-certified transmitter; reliable frame mounting requiring only 10 seconds for installation; industry-standard MC4 connectors with an IP68 enclosure rating for maximum durability; IEC and UL certified for global acceptance; reduced labor time by connecting to two modules to the TS4-A-2F 25A, which enables 16% fewer connections on a 14-panel string compared to single-channel MLPE. Tigo’s rapid shutdown devices provide first-responder safety, and deliver design and installation flexibility for solar installers and EPCs.

Tigo Energy, Inc. | http://www.tigoenergy.com




Volume: 2022 September/October
