Continental Control Systems introduces the new WattNode Wide-Range Modbus meter with several features that simplify installation and reduce hardware costs. New features include a single meter model for services from 100 to 600Vac, remote correction of the current transformer (CT) polarity and phase, ANSI C12.20 class 0.5 accuracy, a 100-millisecond update rate, and the ability to detect disconnected CTs. The versatile power supply replaces seven models with one model. The new model operates from 85Vac to 690Vac on wye, delta, single-phase, and three-phase services. New settings will reduce installation time and hardware costs. Two CTs can be used instead of three CTs for delta circuits, and one CT can be used instead of two CTs for two-wire single-phase circuits. If CT wiring is incorrect, it can be fixed in software remotely after installation. The WattNode's FAST POWER feature measures and reports power, voltage, frequency, and current every 100 milliseconds for power export limiting and control applications. To support new tamper requirements, the WattNode can detect if a CT is disconnected. The WattNode supports potential transformers (PT) for services up to 36 kV and scales measurements based on the PT ratio. The WattNode Wide-Range Modbus uses the Modbus RTU protocol over RS-485 at up to 115,200 baud. It supports millivolt (0.333Vac) output CTs, flexible Rogowski coils, and has optional support for milliamp output CTs. It is available in UL 508A NEMA 4 steel or polycarbonate enclosures with optional fuses or circuit breakers.
