New series of compact DC link film capacitors

TDK Corporation has added to its portfolio of EPCOS film capacitors for DC link applications with the B3277*X/Y/Z series. The new capacitors feature compact dimensions, high capacitance density, and high current capability. They are designed for rated voltages of between 500 and 1200VDC. The series offers numerous standard capacitance values within the range from 1.5 to 170  µF. Depending on the voltage and capacitance, lead spacing is 27.5, 37.5, and 52.5mm, with both 4-pin or 2-pin versions available for each lead spacing. The maximum operating temperature of these RoHS-compatible components is 221 °F (105 °C). At a rated voltage and an operating temperature of 185 °F (85 °C) the typical service life of the self-healing capacitors is 60,000 hours. The MKP capacitors are suitable for use in DC link circuits, as DC filters and for power factor correction for industrial converters, as well as for power supplies with higher reliability requirements. These applications include X-ray equipment, LED street lighting, induction hobs and electrical chargers.

TDK Corporation | www.tdk-electronics.tdk.com
