SolarMax

21 Jul 2013

Product: SolarMax MT A

Application: Residential and commercial solar power plants

Rated Output Power: 12 kW to 18 kW

Weighted CEC Efficiency: 97.3% to 97.5%

Peak Efficiency Range: 97.6% to 98.0%

DC Voltage Operating Range: 250 V to 1000V

Operating Temperature Range: -25°C to + 60°C (-13° F to 140° F)

Dimensions: 21.5" x 37.0" x 7.9"

Certifications/Approvals: FCC Part 15 Subpart B, Class A; IEEE 1547; UL 1741, CSA C22.2 No. 107.1; Intertek

Warranty: 10 years standard, with extended warranty up to 15, 20, or 25 years available



Key Features:

•          With an input voltage of 1000 V, plant operators and investors benefit from low, total system costs and high efficiencies;

•          Three MPP trackers and a broad input voltage range provide the highest level of flexibility, even in the event of asymmetrical divisions of the solar generator or different module types;

•          Lightweight construction and easy to access connections allows for quick and convenient installation; and

•          Integrated RS485 and Ethernet interfaces can be used to design communication networks easily and quickly.



Website: www.solarmax.com


As seen in: SOLAR Spotlight: Commercial Inverters
Volume: July/August 2013
