Advanced Energy Solar Energy

Product: AE 3TL

Application: A three-phase transformerless string inverter for commercial applications

Continuous Output Power: Configurable from 12 kW to 23.2 kW

Weighted CEC Efficiency: 97.5% to 98%

Peak Efficiency Range: 98.2%

DC Voltage Operating Range: 125 V to 450 V

Operating Temperature Range: -25° C to +55° C (-13° F to +131° F)

Dimensions: 21" x 35" x 11"

Certifications/Approvals: Certified to UL 1741 and UL 1998 Standard (for US and Canada) by Underwriters Laboratories

Warranty: 5-year standard warranty, with 10- and 15-year extended warranties



Key Features:

•          Lightweight and easy-to-install, reducing shipping and labor costs, and speeding time to system commissioning;

•          Shortened run-lengths, reducing overall solar PV BoS costs; and

•          Modular and distributed design allows site owners to maximize valuable space on a solar installation, providing increased uptime, higher system yields, and precise trouble-shooting and maintenance.



Website: http://solarenergy.advanced-energy.com/solar-inverters


As seen in: SOLAR Spotlight: Commercial Inverters
Volume: July/August 2013
