Solectria Renewables

21 Jul 2013

Product: PVI 50-100 kW

Application: PV systems 50 kW and greater

Continuous Output Power: 50 kW, 60 kW, 75 kW, 85 kW, and 100 kW

Weighted CEC Efficiency: 96.0% to 97.5% (depending on output power and nominal output voltage)

Peak Efficiency Range: 96.5% to 97.8% (depending on output power and nominal output voltage)

DC Voltage Operating Range: 300 VDC to 500 VDC

Operating Temperature Range: -40° C to + 55° C (-40° F to +131° F)

Dimensions: Side-facing disconnects: 78.2" x 50-53" x 33" (1986 mm x 1270-1346 mm x 838 mm) | Forward-facing disconnects: 78.2" x 79-88" x 33" (1986 mm x 2007-2235 mm x 838 mm)

Certifications/Approvals: UL 1741/IEEE 1547; IEEE 1547.1; CSA C22.2#107.1; FCC part 15B

Warranty: 5-year standard, with 10-, 15-, and 20-year optional warranty; extended service agreement and uptime guarantee



Key Features:

•          Highest peak and CEC efficiencies currently offered in the PV industry;

•          MODBUS communications and user-interactive LCD;

•          Multiple options, including: premium efficient models, fused or breaker subcombiners, forward-facing subcombiners, stainless steel enclosure, sub-array monitoring, built-in cellular connectivity, dust filter;

•          Options for utilities include: real power curtailment, reactive power control, voltage, and frequency ride-through.



Website: www.solectria.com


As seen in: SOLAR Spotlight: Commercial Inverters
Volume: July/August 2013
