solar product spotlight: performance monitoring
SEE AD ON PAGE OBC SEE AD ON PAGE 30
Shoals Technologies Group Product: BLM
Voltage: Systems up to 1500V
Current: 12A Isc
Power: Parasitic
Warranty: 5-year warranty
Logging Values: Voltage, Current Power, Temperature, and IV Curve
Certifications: UL
Key Features:
• String Current, Panel Voltage, and I-V Performance monitoring;
• Continuously monitor for underperforming panels; with wireless communication and parasitic power;
• No need to run cables; easy installation via integrated connectors.
www.shoals.com
Eppley Laboratory
Product: GPP Class A Pyranometer
Warranty: 1-year warranty
Logging Values: .1 Wm-2
Spectral Range: 285-2800 nm
Measurement Range: 0-2800 Wm-2
Output: 0-10 mV Analog or Modbus Digital Output
Sensitivity: 8 μV / Wm-2
Certifications: Calibrated to World Radiation Reference (WRR)
Key Features:
• Class A Pyranometer for high measurement precision and low uncertainty;
• Global/Bi-Facial/Albedo measurements for PV Site Evaluation and Plant Performance;
• Bankable data, unprocessed and unfiltered;
• Flexibility to meet customers unique data requirements;
• Now with digital output.
www.eppleylab.com
Phoenix Contact Product: SOLARCHECK
Logging Values: Modbus communications for external
eGauge Systems Product: eGauge Pro
Voltage: 1-, split-, or 3-phase 0-277Vac and +/-60Vdc
Current: 0-6900A (30 channels) Power: Any current x voltage
combination Frequency: 50/60 Hz
Warranty: 2-year, or 5-year warranty
Logging Values: VAC, VDC, A, W, Wh, Hz, VA, VAr, THD, deg
Certifications: ANSI C12.2 - 0.5% Accuracy, UL (IEC/UL 61010-1 Ed. 3.0 B:2010)
www.egauge.net
Voltage: Up to 8x 0-1500Vdc Current: Up to 64x 0-20Adc Power: Externally calculated
Warranty: Limited lifetime warranty
logging
Certifications: cULus Listed (UL 508 A), UL Recognized (UL 1741)
www.phoenixcontact.com
1500 Volt 30 Amp I-V Curves
Solmetric PV Analyzer
Now shipping V2!
Highest accuracy and throughput
Largest display with best array troubleshooong features
Database of 50,000 PV modules Measures up to 1500V at 30A 3000 wireless sensor range
Expert tools Beeer solar
www.solmetric.com
Electriq Power
Product: PowerPod Residential Energy Storage
System
Voltage: 120/240
Current: 0-30A
Power: 5500W
Frequency: 50Hz and 60Hz
Warranty: 12-year warranty
Logging Values: Dashboard (Electriq Power Software)
Output: 5500W
Certifications: UL 1741SA, UL 1973, UL 1642, CSA C22.2, IEEE 1547A, IEEE 1547.1, FCC Class B, HECO
www.electriqpower.com
