Page 28 - North American Clean Energy Novemeber December 2019 Issue

solar product spotlight: performance monitoring
Performance
Monitoring
Solar performance monitoring systems are necessary to verify the components within a solar system are performing and producing the energy they should. Here, we highlight some of the performance monitoring systems available on the market today.
SEE AD ON PAGE 29
SEE AD ON PAGE 26
Continental Control Systems
Product: WattNode Wide-Range Modbus Energy Meter
Voltage: 100-600 Vac, wye and delta, single-phase, and three-phase
Current: 5 – 6000 Amps Power: 2W
Frequency: 50/60Hz Warranty: 5-year warranty
Output: Requires 0.333 Vac current transformers
Sensitivity: 0.5 % when used with 0.3% current transformers
Certifications: ANSI C12.20, Sunspec Key Features:
• Correct wiring errors remotely;
• Change a CT’s polarity;
• Change a CT to a different line voltage;
• SunSpec, C12.20 certified;
• Updates readings every 100 ms;
• Class 0.5 accuracy.
www.ctlsys.com
Solmetric
Product: PV Analyzer I-V Curve Tracer
Voltage: 1500V
Current: 30A
Power: 45kW
Warranty: 1-year warranty Certifications: TUV
Key Features:
• Measure I-V curves up to 1500V at 30A;
• Wireless interface to irradiance sensor with 300ft range;
• Highest measurement throughput;
• Large, easy-to-use user interface.
www.solmetric.com
Tigo Energy, Inc. Product: TS4-A-2F (Fire Safety
Add-on for 2 Modules up to 1000W) Voltage: 16V - 90V per input Current: 15A per input
Power: 1000W
Warranty: 25-year warranty Spectral Range: Per module
Operating Temperature Range:
-40°F to 158°F (-40°C to 70°C) Certifications: UL, TUV, IP68,
Fronius
Product: Fronius Symo Advanced Voltage: 600V - 1000V
Current: 25.0A / 16.5A
Power: Multiple
Frequency: 45 - 65Hz
Certifications: UL 1741-2010 Second Edition (including UL1741 Supplement SA 2016-09 for California Rule 21 and Hawaiian Electric Code Rule 14H), UL1998 (for functions: AFCI, RCMU and isolation monitoring), IEEE 1547-2003, IEEE 1547.1-2003, ANSI/
Frequency: Powerline communication
NEMA 3R
www.tigoenergy.com
Warranty: 10-year warranty Logging Values: 10 - 24kW
IEEE C62.41, FCC Part 15 A & B, NEC 2017 Article 690, C22. 2 No. 107.1-16, UL1699B Issue 2 -2013, CSA TIL M-07 Issue 1 -2013
www.fronius.com
Spectrafy
Product: SolarSIM-G spectral
pyranometer
Voltage: 12Vdc
Power: <1W
Warranty: 5-year warranty
Spectral Range: 280-4000nm Measurement Range: 280-4000nm Output: RS-485 ASCII
Sensitivity: <1%
Certifications: ISO 9080:2018 Class A www.spectrafy.com
